I. Main features:

1. Side-gather & lamination panty liner can be produced;
2. Touch screen is adopted for man machine conversation;
3. Inverter governor adopted for main machine drive; PLC control;
4. Active unwinding and splicing units are adopted for raw material;
5. Auto detects & alarm for material exhausted; auto reject for waste caused by splicing;
6. Square supports are adopted for frame of rotary bodies & cutters.;
7. Protective door is equipped.

II. Main technical parameter:

1. Supply:3 phase, 380V, 50Hz;
2. Power: 48Kw (Hot melt machine & air compressor excluded);
3. Wastage:≤2%;
4. Production speed: 600pcs/min;
5. Outside dimension(m):12.5×4.5×2.5 (L×W×H) ;

III. Main structural device:

1. Top sheet lamination unit;
2. Top sheet embossing unit;
3. Absorbent paper splitting unit;
4. Contour embossing unit;
5. Release paper splitting unit;
6.  Forming cutting unit;
7. 90°rotating unit;
8. Constant interval order unit;
9.  Sachet wrapping unit;
10.  Adhesive tape splitting unit;
11. Thermo-sealing & cutting unit;
12. Finished products outputting unit.
